LED light engines for light guide illuminators by Innovations in Optics

Dec. 16, 2014

LumiBright Model 2400B-400-W and 2400B-500-W high-power white LED light engines from Innovations in Optics couple directly to liquid light guides and fiber bundles with no additional optics, delivering up to 4000 lumens into the light guide.

BioOptics World Editors

Content Dam Bow Online Articles 2014 12 2400b W Web

LumiBright Model 2400B-400-W and 2400B-500-W high-power white LED light engines from Innovations in Optics (Woburn, MA) couple directly to liquid light guides and fiber bundles with no additional optics, delivering up to 4000 lumens into the light guide. The 2400B-400-W has a 0.66 numerical aperture (NA) and illuminates fiber bundles and light guides sized from 6.0 to 8.0 mm in diameter. 2400B-500-W, which produces up to 1500 lumens, has utility in endoscopy and microscopy illumination applications with a 0.60 NA for light guides that are 3.0 to 5.0 mm in diameter.

For more information, please visit www.innovationsinoptics.com.
