Master Bond electrically conductive epoxy meets NASA low-outgassing specs

May 25, 2011
EP21TDCS-LO is an electrically conductive silver-filled epoxy that passes ASTM 595 for NASA low-outgassing specifications.

EP21TDCS-LO is an electrically conductive silver-filled epoxy that passes ASTM 595 for NASA low-outgassing specifications. The adhesive cures at room temperature in 24–48 hours and in just 1–2 hr at 200ºF, with a tensile shear strength >1800 psi, a T-peel >5 pli and a temperature range of 4K to 275ºF.
Master Bond
Hackensack, NJ
[email protected]

More Products

-----

PRESS RELEASE

Silver Conductive Epoxy Meets NASA Low Outgassing Standards

HACKENSACK, NJ - February 8, 2011 - Master Bond EP21TDCS-LO is an electrically conductive silver-filled epoxy that passes ASTM 595 for NASA low outgassing specifications. It is widely used for demanding applications in the electronic, electrical, computer, semiconductor, aerospace and optical industries.

The adhesive cures at room temperature in 24-48 hours and in just 1-2 hrs at 200ºF, producing tough high strength bonds. It features a tensile shear strength of more than 1,800 psi, a T-peel of greater than 5 pli, and outstanding adhesion to similar and dissimilar substrates. The volume resistivity of the system is less than 10-3 ohm-cm. Serviceable over the exceptionally wide range of 4K to 275ºF, EP21TDCS-LO is suitable for cryogenic applications. It withstands thermal cycling and is resistant to chemicals, including water, oil and most organic solvents.

The epoxy offers a simple 1 to 1 mixing ratio by weight or volume. With its low drip formula, EP21TDCS-LO can be conveniently applied with a syringe, knife, spatula or trowel to vertical surfaces without sagging and only contact pressure is required for curing. Syringes have a 3 month shelf life and glass jars have a 6 month shelf life, if stored at room temperature. EP21TDCS-LO is available in premixed and frozen syringes, as well as in metal containers.

Master Bond Electrically Conductive Adhesives

Master Bond's Polymer System EP21TDCS-LO was developed for high performance bonding and sealing where superior electrical conductivity and NASA low outgassing certification is required. Read more about Master Bond's electrically conductive adhesives at http://www.masterbond.com/lp/tabs/tp_pp_eleccond.html or contact Technical Support by phone at +1-201-343-8983, by fax at +1-201-343-2132 or by e-mail at [email protected].

-----
