An all-in-one compact electronic autocollimator includes an LED, CCD camera, measurement software, and integrated X-Y tilt mechanics. The system measures minute angular displacements for various optical setups and alignment tasks. It includes a coarse-alignment telescope, leveling bubble, adjustment pan tilt knobs, and USB 2.0 connector. It has resolution of 0.1 s and accuracy of 2.5 s.
Duma Optronics
Nesher, Israel
[email protected]
-----
PRESS RELEASE
New Electronic Autocollimator
All in one compact autocollimator including LED, CCD camera, measurement software and integrated X-Y tilt mechanics.
The system measures minute angular displacements for various optical setups alignment tasks. The system offers portable, compact and accurate beam alignment solution. The precision electronic autocollimator has built in adjustment features, such as coarse alignment telescope, leveling bubble, adjustment pan tilt knobs, enhancing the unprecedented alignment procedure.
Main Applications:
-Measurement of mirror angle
-Straightness measurement of linear stages
-Characterization of rotation stage
-Measurement of surface flatness
Specifications:
Autocollimator 42' (H) (2520 sec of arc)
Telescope 84' (H) (5040 sec of arc)
Resolution 0.1sec
Accuracy 2.5sec
CCD Camera, LED light source, USB2.0
Duma Optronics Ltd.
Nesher. Israel.
www.duma.co.il
[email protected]
-----
